The Honeywell MU-TPIX12 51304084-100 is a high-quality Pulse Input Termination Board designed for Experion LS and FS series automation systems. It provides secure and accurate termination for multiple pulse input signals from flow meters, counters, and other field devices. Engineered for industrial reliability, the MU-TPIX12 ensures signal integrity, minimizes noise interference, and simplifies field wiring, making it ideal for process, energy, and manufacturing automation applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model | MU-TPIX12 / 51304084-100 |
| Module Type | Pulse Input Termination Board |
| Input Type | Pulse inputs from flow meters, counters, and other field devices |
| Number of Channels | 12 pulse input channels |
| Signal Voltage | 5–24 V DC |
| Input Frequency Range | Up to 10 kHz |
| Operating Temperature | 0 °C to +60 °C |
| Mounting | DIN rail or panel mount compatible |
| Dimensions (W×H×D) | 120 mm × 90 mm × 25 mm |
| Weight | ~0.22 kg |
| Isolation | Electrically isolated channels to protect the controller |
| Material | Industrial-grade PCB with protective coating |
This termination board provides accurate and reliable input processing while protecting controllers from electrical faults and signal interference.
