Introduction
The HIMA F3300 is a safety-rated controller module from the HIMA HIMatrix/F3000 family, designed for critical industrial safety and automation applications. It acts as the central safety CPU — managing logic, inputs/outputs, diagnostics, and safety-related control functions. Its architecture supports high integrity, redundancy, and flexible I/O configurations, making it suitable for demanding environments such as petrochemical plants, power generation, oil & gas, and large process industries.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | F3300 |
| Module Type | Safety Controller / Safety CPU Module |
| Safety Integrity Level | SIL‑3, compliant with IEC 61508 / IEC 61511 |
| I/O Capabilities | Configurable digital, analog, and serial I/O depending on system setup |
| Output Channels | 8 digital outputs (standard configuration) |
| Output Voltage | 24 V DC nominal |
| Output Current / Load Capacity | Up to 2 A per output (short‑circuit proof); normal load 500 mA per channel |
| Cycle Time / Processing Speed | As low as 500 µs for fast safety logic execution |
| Memory / Storage | 16 MB for application code, data, and diagnostics |
| Rack Space / Slot Size | Occupies 4 TE in standard HIMatrix rack chassis |
| Operating Temperature | –20 °C to +60 °C |
| Redundancy / Fault Tolerance | Supports redundant configurations for fail-safe operation |
| Dimensions (H × W × D) | 150 × 32 × 185 mm |
| Weight | 1.2 kg |
