Woodward 5466-1049 TMR Kernel Power Supply Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Woodward 5466-1049 TMR Kernel Power Supply Module

Name: Woodward 5466-1049 TMR Kernel Power Supply Module
Brand: Woodward
SKU: 265
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Woodward
Item No.:5466-1049
Product Origin:USA
Product Dimensions:150 × 32 × 185 mm
Product Weight:0.6 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Woodward 5466-1049 is a TMR (Triple-Modular-Redundant) Kernel Power Supply Module designed for 5466-series MicroNet and TMR control systems. It provides reliable and stable power to CPU modules and associated I/O modules in critical industrial turbine, engine, and generator control applications. Engineered for redundancy, robustness, and continuous operation, this module ensures that TMR systems maintain full functionality even in the event of partial power disruptions.

Technical Specifications

Parameter	Specification
Model Number	5466-1049
Module Type	TMR Kernel Power Supply Module
Input Voltage	24 V DC nominal
Output Voltage	Regulated supply for CPU and I/O modules (internal TMR power distribution)
Redundancy	Designed for triple-modular redundant operation
Communication	Backplane interface for monitoring status and fault signals
Operating Temperature	–40 °C to +70 °C
Mounting	Rack-mounted within 5466-series control chassis
Dimensions (H × W × D)	150 × 32 × 185 mm
Weight	0.60 kg

Applications

Provides reliable, redundant power for 5466-series TMR CPU and I/O modules
Ensures continuous operation of turbine, engine, and generator control systems
Industrial automation in power plants, compressor stations, and marine propulsion
Retrofit upgrades or replacement of aging power supply modules in redundant control systems
Systems requiring high availability and fail-safe operation under harsh environmental conditions

Advantages

Redundant design ensures system continuity even if one power path fails
Stable, regulated output maintains proper operation of all connected modules
Industrial-grade construction suitable for high vibration, temperature, and electrical noise environments
Rack-mounted modular form factor allows easy replacement without system downtime
Compatible with TMR kernel architecture for seamless integration into critical control loops

Technical FAQs

What is the primary function of the 5466-1049?
It provides regulated, redundant power to CPU and I/O modules in a TMR system.
What input voltage does it require?
Nominal 24 V DC.
Can it operate in TMR redundant systems?
Yes, it is specifically designed for triple-modular-redundant operation.
What are its operating temperature limits?
–40 °C to +70 °C.
What modules does it power?
5466-series CPU modules and associated I/O modules in TMR configuration.
Is it rack-mounted?
Yes, it installs into standard 5466-series racks.
How does it handle power faults?
Its redundant design ensures continuous operation even if one supply path fails.
What is the approximate size and weight?
Dimensions: 150 × 32 × 185 mm; Weight: 0.60 kg.
Is it suitable for harsh industrial environments?
Yes, it tolerates vibration, temperature variations, and electrical noise.
Can it be used in retrofits?
Yes, it is commonly used to replace older power supply modules in TMR systems.
