Woodward 5466-1002 Control Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Woodward 5466-1002 Control Module

Name: Woodward 5466-1002 Control Module
Brand: Woodward
SKU: 258
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Woodward
Item No.:5466-1002
Product Origin:USA
Product Dimensions:152 × 32 × 185 mm
Product Weight:0.7 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Woodward 5466-1002 is an industrial-grade control module designed for high-reliability turbine, engine, and generator automation systems. Engineered for precise closed-loop performance, it provides stable process control, strong signal conditioning, and dependable operation in demanding industrial environments.
Its architecture supports rapid control response and seamless integration within Woodward’s 5400/5466-series racks, making it a trusted component in both new installations and legacy-system modernization projects.

Technical Specifications

Parameter	Details
Model	Woodward 5466-1002
Module Type	Control Module
Power Input	24 VDC nominal
Inputs	Digital status inputs, analog feedback channels, speed/proximity sensor interfaces
Outputs	Relay outputs, analog command signals
Communication	Internal 5400/5466-series backplane bus
Operating Temperature	–20°C to +70°C
Installation Method	Rack-mounted module (5400/5466-series)
Dimensions (H × W × D)	152 × 32 × 185 mm
Weight	0.70 kg

Applications

The 5466-1002 supports a wide range of industrial control scenarios, including turbine governor systems, compressor regulation, engine automation, generator load-control modules, and marine propulsion machinery.
It is commonly employed in facilities where stable, continuous operation is essential, such as power plants, petrochemical units, and large rotating-equipment installations.

Advantages

High operational stability for continuous-duty turbine and engine control
Fast loop response, ideal for speed, load, and fuel-regulation applications
Robust noise immunity, ensuring stable performance in harsh industrial environments
Clear diagnostic indicators, helping maintenance personnel quickly locate faults
Flexible I/O capability, allowing interoperability with a broad range of industrial sensors
Long service life supported by rugged electronic design and proven reliability

Technical FAQs

Does the 5466-1002 support field configuration?
Yes, but configuration changes require authorized tools and procedures.
Is this module hot-swappable?
No. Power should be removed before installation or removal.
What rack does it mount into?
It installs into the Woodward 5400/5466-series rack architecture.
Does it include analog feedback processing?
Yes, it supports multiple analog channels for speed and process inputs.
Are diagnostic LEDs included?
Yes, LEDs provide module health and communication status.
What is the normal power consumption?
Approximately 8–12 W, depending on connected I/O.
Is it compatible with magnetic pickup sensors?
Yes, through the control system’s speed-sensing interfaces.
Can it be used to upgrade older systems?
Frequently used for modernization of aging Woodward controllers.
Does the module support protective functions?
It contributes to system-level protection such as overspeed and actuator safety.
Which industries commonly use this module?
Power generation, oil & gas, petrochemical processing, marine systems, and industrial rotating machinery.
