Introduction
The OVATION 1C31166G02 is an upgraded digital output module designed to deliver precise, reliable switching performance within OVATION Distributed Control Systems. This revision enhances output stability and channel protection, making it suitable for demanding environments where discrete actuation must operate continuously without degradation. Engineers rely on this module to interface control logic with field-level equipment such as relays, interlocks, solenoids, and discrete actuators while maintaining long-term electrical integrity.
Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Digital Output Module |
| Part Number | 1C31166G02 |
| Output Channels | 16 isolated digital outputs |
| Output Type | Relay/solid-state output depending on load configuration |
| Nominal Output Voltage | 24 V DC |
| Maximum Output Current | 0.5 A per channel |
| Isolation Rating | 1500 V RMS (channel-to-backplane) |
| Switching Time | < 5 ms typical |
| Built-In Protection | Overcurrent and transient suppression (module-level) |
| Power Consumption | < 7 W |
| Operating Temperature | –10 °C to +60 °C |
| Humidity | 5%–95% non-condensing |
| Dimensions | 165 × 32 × 110 mm (H × W × D) |
| Weight | 0.48 kg |
| Installation | OVATION digital output slot, rear-plane connector |
