OVATION 1C31099H01 I/O Module

Name: OVATION 1C31099H01 I/O Module
Brand: Ovation DCS
SKU: 240
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Ovation DCS
Item No.:1C31099H01
Product Origin:USA
Product Dimensions:165 × 32 × 110 mm
Product Weight:0.45 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The OVATION 1C31099H01 is an input/output (I/O) module designed for the OVATION Distributed Control System (DCS). From an engineer’s perspective, this module serves as a critical interface between field devices (sensors and actuators) and the control system. It reliably captures signals from the process environment, transmits them to the controller, and outputs control commands, ensuring stable and precise system operation in industrial plants, power stations, and process facilities.

Technical Specifications

Parameter	Specification
Module Type	Input/Output (I/O) Module
Model / Part No.	1C31099H01
Function	Interfaces with analog/digital field devices; processes input and output signals
Compatibility	OVATION DCS racks
Input Signal Types	Analog: 4–20 mA, 0–10 V; Digital: contact closures or logic-level signals
Output Signal Types	Analog: 4–20 mA, 0–10 V; Digital: relay/contact outputs
Operating Temperature	0 °C to 60 °C
Storage Temperature	–40 °C to +85 °C
Humidity Tolerance	5% to 95% non‑condensing
Dimensions	165 × 32 × 110 mm (H × W × D)
Weight	0.45 kg
Mounting	Standard OVATION rack-mountable module

Applications

Collecting sensor signals from process equipment such as pumps, turbines, and valves
Delivering control signals to actuators, relays, and other field devices
Supporting real-time process monitoring and automated control in power plants, chemical plants, and industrial facilities
Replacement or expansion module in existing OVATION DCS systems
Integration in predictive maintenance and process optimization schemes

Advantages

Reliable signal processing — ensures accurate communication between field devices and control logic
Versatile interface — supports both analog and digital inputs and outputs
Compact and lightweight — easy to install and maintain at 0.45 kg
Industrial-grade tolerance — operates under wide temperature and humidity ranges
Rack-compatible — fits seamlessly into OVATION DCS racks for straightforward integration

Technical FAQs

What is the primary function of 1C31099H01?
It provides analog and digital input/output interfacing between field devices and the OVATION DCS.
Which signal types are supported?
Analog: 4–20 mA and 0–10 V; Digital: contact closures or logic-level signals.
What output signals does it provide?
Analog: 4–20 mA, 0–10 V; Digital: relay/contact outputs.
What is the operating temperature range?
0 °C to 60 °C; storage –40 °C to +85 °C.
Is it compatible with all OVATION racks?
Yes, designed to fit standard OVATION DCS racks.
What is the module’s weight?
0.45 kg, lightweight for easy handling.
What are the dimensions of the module?
165 × 32 × 110 mm (H × W × D).
Can it be used for retrofitting existing systems?
Yes, suitable for replacement or expansion of existing OVATION systems.
How does it support industrial environments?
Operates reliably under 5%–95% non-condensing humidity and standard ambient temperatures.
What types of applications typically use this module?
Process automation, power generation, chemical processing, and any industrial facilities requiring field-to-control interfacing.
