Introduction
The Bently Nevada 3500/62 ±10 Vdc Input/Output Module (136499-01) is designed to integrate analog voltage signals into the 3500 Machinery Protection System. It supports both input and output signals in the range of −10 Vdc to +10 Vdc, enabling reliable communication between external instrumentation, control systems, and the protection platform.
The module’s external terminal design simplifies wiring and maintenance, making it suitable for installations where precise voltage-based signal handling and system reliability are essential. Its architecture ensures seamless integration with other 3500 monitoring and protection modules.
Technical Specifications
| Item | Description |
|---|
| Product Type | Analog Voltage Input/Output Module |
| Model Series | 3500/62 |
| Part Number | 136499-01 |
| Signal Range | −10 Vdc to +10 Vdc input/output |
| Termination | External field terminals |
| Functional Role | Analog signal acquisition and output |
| System Platform | Bently Nevada 3500 Series |
| Signal Processing | Continuous real-time handling of voltage signals |
| Diagnostic Features | Built-in module health monitoring |
| System Interface | 3500 backplane communication |
| Installation | Rack-mounted module |
| Dimensions | 241.3 × 24.4 × 99.1 mm |
| Weight | 0.2 kg |
Applications
• Analog Voltage Signal Integration
Supports acquisition and output of ±10 Vdc signals representing process or control variables.
• Interfacing with Control and Automation Systems
Enables reliable exchange of analog data between the 3500 system and plant control systems.
• Flexible Field Wiring in Industrial Panels
External terminals facilitate straightforward installation, maintenance, and wiring management.
Advantages
• Accurate Bidirectional Voltage Handling
Ensures precise input and output voltage management without signal distortion.
• Simplified Maintenance Through External Terminals
External wiring points make installation, inspection, and replacement more efficient.
• Seamless Integration with the 3500 Platform
Works reliably alongside other 3500 monitoring and protection modules, preserving system integrity.
Technical FAQs
1. What signal range does the 136499-01 module support?
It supports ±10 Vdc analog voltage signals for both input and output.
2. Can it handle only input signals?
No. It supports both input and output voltage signals.
3. Why does the module have external terminals?
External terminals simplify field wiring and maintenance activities.
4. Can this module operate outside a 3500 system?
No. It must be installed within a Bently Nevada 3500 rack.
5. Does the module provide electrical isolation?
No. It focuses on voltage I/O functionality, not isolation.
6. How does it communicate with the 3500 system?
Through the 3500 backplane interface.
7. Is it suitable for continuous industrial operation?
Yes. The module is designed for continuous duty.
8. Can it be used alongside vibration, temperature, or speed modules?
Yes. It is fully compatible with other 3500 modules.
9. What is the role of this module in machinery protection?
It provides voltage signals to support monitoring logic and coordinated protection actions.
10. How is it different from current-loop I/O modules?
It is designed specifically for voltage-based signals rather than +4 to +20 mA current loops.
