ABB 5SHY3545L0016 3BHB020720R0002 High-Power IGCT Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB 5SHY3545L0016 3BHB020720R0002 High-Power IGCT Module

Name: ABB 5SHY3545L0016 3BHB020720R0002 High-Power IGCT Module
Brand: ABB PLC
SKU: 210
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:5SHY3545L0016 3BHB020720R0002
Product Origin:Sweden
Product Dimensions:200 × 180 × 85 mm
Product Weight:8 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The ABB 5SHY3545L0016 (also referenced as 3BHB020720R0002) is a high-capacity IGCT (Insulated Gate Commutated Thyristor) module designed for heavy-duty industrial and utility-scale power applications. This overview takes a field-engineer perspective, focusing on practical deployment, thermal management, and operational reliability. Modules like this are critical in high-power converters, HVDC systems, and large industrial motor drives.

Technical Specifications

Parameter	Description
Model Numbers	5SHY3545L0016 / 3BHB020720R0002
Device Type	High-Power IGCT Module
Voltage Rating	Approximately 6.5–7 kV
Current Rating	~3545 A (system-dependent)
Function	High-current, high-voltage switching for industrial drives, converters, and HVDC applications
Cooling Requirement	Requires forced air or liquid cooling with high-efficiency heatsinks
Gate Drive	Dedicated IGCT gate driver mandatory
Isolation	High-voltage creepage and clearance standards compliant
Dimensions	200 × 180 × 85 mm (H × W × D)
Weight	~8.0 kg

Applications

Industrial medium- and high-voltage motor drives
HVDC transmission converter stations
Large AC/DC and DC/AC converters in power plants or industrial sites
FACTS systems for reactive power and voltage control
High-power industrial rectifiers and inverters
Retrofit or replacement in existing ABB IGCT-based power systems

Advantages

Extreme power capacity — capable of handling very high current and voltage demands.
Robust industrial construction — engineered for continuous operation in harsh environments.
Predictable switching performance — ensures precise operation in high-power converter systems.
Thermally stable — supports consistent performance under heavy-load operation with proper cooling.
Legacy compatibility — facilitates maintenance and upgrades without requiring full system redesign.

Technical FAQs

What is the main function of this module?
High-current, high-voltage switching for industrial drives, converters, and HVDC applications.
Is it compatible with other ABB IGCT modules?
Only with modules of similar voltage/current ratings and compatible form factors.
Does it require a dedicated gate driver?
Yes, a proper IGCT gate-drive unit is mandatory for safe operation.
How should it be cooled?
Forced air or liquid cooling is necessary to maintain safe junction temperatures.
Can it be mounted in any orientation?
Orientation is flexible, but uniform thermal interface pressure is required.
Is it suitable for high-frequency switching?
IGCTs are optimized for lower switching frequencies typical in high-power industrial applications.
What happens if cooling is inadequate?
Overheating can lead to reduced lifespan or immediate device failure.
Can it handle regenerative current flow?
Yes, suitable for bidirectional applications in regenerative drive systems.
Are there special handling requirements?
Handle carefully to avoid mechanical shock and follow electrostatic discharge precautions.
Where is this module typically used?
HVDC converter stations, high-power industrial motor drives, FACTS systems, and large-scale rectifier or inverter installations.
