Introduction
The Honeywell FC‑TSRO‑08UNI Digital Output Field Termination Assembly is a robust and versatile interface solution designed to terminate and organize digital output signals from industrial control systems. Built for reliable performance in demanding environments, this assembly streamlines field wiring and enhances signal integrity for 8 output channels. It is ideal for automation panels, distributed control installations, and field junction boxes where structured termination, serviceability, and electrical protection are priorities.
Technical Specifications
| Feature | Specification |
|---|---|
| Model | FC‑TSRO‑08UNI |
| Type | Digital Output Field Termination Assembly |
| Output Channels | 8 points |
| Output Signal Type | Discrete digital outputs |
| Compatible Voltage | 24 VDC industrial signals |
| Terminal Type | Screw‑type, positive locking contacts |
| Wire Size Range | 12–24 AWG (0.2–4.0 mm²) |
| Current Rating | Up to 5 A per channel |
| Voltage Rating | Up to 30 V DC |
| Isolation | Passive terminal isolation |
| Mounting | DIN rail or panel mount |
| Operating Temperature | −20 °C to 70 °C |
| Storage Temperature | −40 °C to 85 °C |
| Dimensions (W × H × D) | 210 mm × 95 mm × 45 mm |
| Weight | 0.78 kg |
| Environmental | Industrial grade, vibration and impact resistant |
