ABB 3BHB002953R0102 Control / Drive Module

Brand:ABB PLC
Item No.:3BHB002953R0102
Product Origin:Sweden
Product Dimensions:120 × 120 × 20 mm
Product Weight:0.51 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

Introduction

The ABB 3BHB002953R0102 is a module associated with ABB’s medium-voltage drive systems (notably the ACS-1000 series), serving as a core control/measurement element within the drive. This white-paper style overview treats the module in the context of industrial drive and power-electronics integration, emphasizing its role in current measurement/scaling, protection, and reliable drive operation rather than marketing-style descriptions.

Technical Specifications

Parameter Description
Module Type Control / Current-Measurement / Drive Interface Module
Model / Part Number 3BHB002953R0102
Intended System ABB ACS-1000 (medium-voltage drive system)
Function / Role Current measurement / scaling and drive control interface
Input Voltage (Drive Supply) 220–480 V AC (typical for medium-voltage drive input side)
Nominal Current Capacity 30 A (as part of drive system capacity)
Operating Temperature Range –25 °C to +70 °C
Humidity / Environment Tolerance Up to 90% RH (non-condensing) in controlled industrial cabinet environments
Mechanical Dimensions ≈ 120 × 120 × 20 mm
Typical Weight ≈ 0.51 kg

Applications

  • As part of a medium-voltage variable frequency drive (VFD) system requiring precise current measurement, scaling, and control logic.

  • Industrial applications involving heavy motors, pumps, compressors or large machinery controlled via ABB ACS-1000 drives.

  • Retrofit or spare-part provisioning for existing ABB medium-voltage installations where maintaining original drive architecture is desired.

  • Systems needing built-in overload, short-circuit protection, and electrical parameter monitoring integrated with drive control.

  • Environments using combined automation and power-electronics systems — such as utilities, wastewater treatment, large HVAC, or process plants — where stability and reliability matter.

Advantages

  • Integrated current measurement and control — offers embedded measurement/scaling functionality to handle drive-side current feedback and monitoring.

  • Compatibility with ABB medium-voltage drives — designed to integrate seamlessly into ACS-1000 drive systems without custom adaptation.

  • Compact and lightweight — modest card size and weight make it suitable as a modular replaceable component in drive cabinets.

  • Robust design for industrial environment — wide temperature range, humidity tolerance, and design for AC supply conditions common in large-scale drives.

  • Supports protective functions — includes provisions for overload and short-circuit detection to protect both the module and connected equipment.

Technical FAQs

  1. What is the primary role of 3BHB002953R0102?
    It serves as the current-measurement and scaling control module inside an ABB medium-voltage drive, contributing to both control and protection functions.

  2. What voltage and current ranges does it support?
    The drive input range is typically 220–480 V AC, and the module is designed for nominal current handling around 30 A (within the drive’s overall capacity).

  3. Is it suitable for heavy industrial motor control?
    Yes — as part of the ACS-1000 drive system, it supports heavy-duty industrial motor and load control in demanding environments.

  4. Can it detect overload or short-circuit conditions?
    Yes — the module incorporates overload and short-circuit protection and monitoring capabilities to help safeguard the drive and connected equipment.

  5. What environment can it operate in?
    It’s rated for –25 °C to +70 °C and up to 90% relative humidity (non-condensing), making it well-suited for standard industrial cabinets.

  6. Is it easy to replace or maintain?
    Yes — its modular form factor and card-style design facilitate replacement or swap-out as a spare part in drive cabinets.

  7. Can this module be used outside ABB ACS-1000 drives?
    Generally no — it’s designed specifically for the ACS-1000 medium-voltage drive architecture, so compatibility with other systems may be limited.

  8. What kind of outputs or interfaces does it provide?
    It handles internal drive control and measurement signals (current, scaling, protection), interfacing with the drive’s internal control logic — not a general-purpose I/O module.

  9. Is it suitable for modern retrofit or upgrade projects?
    Yes — especially in plants where the existing ABB medium-voltage drive infrastructure is retained and only maintenance/spare parts are needed.

  10. How reliable is it for long-term industrial use?
    The module is built for industrial-grade duty — its design temperature and environmental tolerances, combined with protective functions and integration into a proven drive platform, make it a reliable component for long-term operation.
