Technical FAQs

1. What is the purpose of the Bently Nevada 3500/34 TMR Relay Module?

   • The 3500/34 TMR Relay Module is used to provide relay outputs for critical machinery protection in Bently Nevada’s 3500 Series, designed to prevent system failures and ensure operational stability.

2. How many relay outputs does the 3500/34 provide?

   • The module provides 4 relay outputs, each configured as SPDT (Single Pole Double Throw).

3. What is the operating temperature range for the 3500/34?

   • The 3500/34 operates within a temperature range of -40°C to 70°C, making it suitable for various industrial environments.

4. What is the power consumption of the 3500/34?

   • The typical power consumption of the module is 1.5 W, ensuring efficient operation.

5. How is the 3500/34 mounted?

   • The module is designed for rack mounting, ensuring secure and stable integration with the Bently Nevada 3500 Series.

6. What compliance standards does the 3500/34 meet?

   • The 3500/34 complies with CE, UL, and RoHS standards, ensuring safety, environmental compliance, and quality.

7. Can the 3500/34 be used in hazardous environments?

   • Yes, the 3500/34 is designed for industrial environments, and additional certifications like ATEX may be necessary for use in hazardous areas.

8. What relay type does the 3500/34 use?

   • The module uses SPDT (Single Pole Double Throw) relays for flexible output control.

9. What voltages does the 3500/34 support?

   • The 3500/34 supports 125 VDC and 24 VDC operating voltages, depending on the system configuration.

10. Is the 3500/34 compatible with other Bently Nevada modules?

    • Yes, the 3500/34 is fully compatible with other modules in the 3500 Series, ensuring seamless integration for machinery protection and monitoring.
