Bently Nevada 3500/32 149986-02 + 125720-01 4-Channel Relay Control Module + Output Module

Brand:Bently Nevada PLC
Item No.:3500/32
Product Origin:USA
Product Dimensions:241 x 24.4 x 242 mm
Product Weight:0.7 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

Introduction

The Bently Nevada 3500/32 149986-02 + 125720-01 4-Channel Relay Control Module + Output Module is an integrated solution designed for machinery protection, condition monitoring, and control in industrial applications. Combining four relay control channels with four output channels, this module ensures efficient alarm management, shutdown triggering, and system diagnostics. The 149986-02 control module provides backup functionality and control, while the 125720-01 output module offers reliable relay outputs for alarm and emergency shutdown systems. Together, they form a robust protection system ideal for critical applications in industries such as power generation, oil & gas, and manufacturing.

Technical Specifications

SpecificationDetails
ModelBently Nevada 3500/32 149986-02 + 125720-01
Type4-Channel Relay Control Module + Output Module
Dimensions241 x 24.4 x 242 mm
Weight0.7 kg
Power Supply24V DC (Nominal)
Relay Output Channels4 Channels
Relay TypeSPDT (Single-Pole Double-Throw)
Relay Switching Capacity1 A @ 30V DC / 0.5 A @ 125V AC
Control Module FunctionalityBackup control, system diagnostics
Output Module FunctionalityRelay outputs for alarms, shutdowns
Operating Temperature Range-20°C to 60°C
Storage Temperature Range-40°C to 85°C
Mounting TypeRack or Panel Mounting
CertificationsCE, UL, RoHS


Applications

The Bently Nevada 3500/32 149986-02 + 125720-01 4-Channel Relay Control Module + Output Module is used in industrial environments where continuous monitoring and protection of critical machinery are essential. Its applications include:

  • Machinery Protection: Provides four relay channels for emergency shutdowns and alarms in turbine, compressor, and motor protection systems.

  • Condition Monitoring: Enables real-time monitoring of equipment and triggers alarms and shutdowns in response to abnormal conditions, protecting machinery from damage.

  • Oil & Gas: Used in upstream, midstream, and downstream operations to monitor and protect critical machinery such as pumps, compressors, and motors.

  • Power Generation: In power plants, the module facilitates the protection and fault detection of turbines, generators, and other essential infrastructure.

  • Industrial Automation: Offers reliable control and monitoring for manufacturing systems, ensuring protection against failures and enabling fault detection and recovery.

  • Process Control Systems: Provides reliable backup and output functions in process industries, preventing downtime and ensuring equipment safety.


Advantages

  • Integrated Control and Output Modules: The system combines control and output modules to provide backup control, system diagnostics, and reliable relay outputs for alarms and shutdowns, ensuring maximum operational safety.

  • Four Independent Channels: Both the control and output modules offer four isolated relay channels, providing flexibility for multiple monitoring points and control functions.

  • SPDT Relay Type: The module features SPDT (Single-Pole Double-Throw) relays, providing versatile switching for control and alarm devices in critical systems.

  • High Switching Capacity: Each relay can handle 1 A at 30V DC or 0.5 A at 125V AC, suitable for a wide range of industrial control and monitoring applications.

  • System Diagnostics: The control module offers real-time system diagnostics, helping to detect faults early and prevent system failures.

  • Rugged and Reliable: Designed to operate in harsh industrial environments, the module has an operating temperature range of -20°C to 60°C, ensuring durability in demanding conditions.

  • Compact and Space-Efficient: The module's compact design allows it to be mounted in rack or panel configurations, saving space while offering full functionality.

  • Energy Efficient: Powered by 24V DC, the module ensures energy-efficient operation while maintaining high performance and reducing operational costs.

  • Certified for Safety: The module is certified with CE, UL, and RoHS, ensuring it meets international standards for safety, quality, and environmental compliance.

  • Seamless Integration: Integrates seamlessly with the Bently Nevada 3500 system, providing enhanced protection and monitoring capabilities without complex configuration.


Technical FAQs

  1. How many relay channels does the Bently Nevada 3500/32 module provide?
    The module provides four independent relay channels, offering flexible control for various industrial systems.

  2. What type of relays are used in the Bently Nevada 3500/32 module?
    The module features SPDT (Single-Pole Double-Throw) relays, allowing for versatile switching options for control and monitoring devices.

  3. What power supply is required for the Bently Nevada 3500/32 module?
    The module operates with a 24V DC nominal power supply.

  4. What is the relay switching capacity of the Bently Nevada 3500/32 module?
    Each relay can handle 1 A at 30V DC or 0.5 A at 125V AC, making it suitable for controlling a wide variety of industrial devices.

  5. What is the role of the control module in this system?
    The control module offers backup control, system diagnostics, and real-time monitoring to ensure the continuous operation and protection of critical machinery.

  6. What is the function of the output module?
    The output module provides relay outputs for alarms and emergency shutdowns, enabling rapid response to equipment failures and protecting machinery from damage.

  7. How is the Bently Nevada 3500/32 module mounted?
    The module can be mounted in rack or panel configurations, allowing for flexible installation in control systems.

  8. What is the operational temperature range for this module?
    The Bently Nevada 3500/32 module operates effectively within a temperature range of -20°C to 60°C.

  9. What certifications does this module hold?
    The module is certified for CE, UL, and RoHS, ensuring compliance with international safety and environmental standards.

  10. How does the Bently Nevada 3500/32 module contribute to machinery protection?
    It provides backup control, system diagnostics, and relay outputs for alarms and emergency shutdowns, ensuring continuous machinery protection and minimizing downtime.
