Introduction
The Honeywell CC‑PUIO01 51454205‑175 Universal I/O Module is a flexible input/output interface designed for Honeywell C300 distributed control systems (DCS). This module supports both analog and digital I/O functions within a single platform, simplifying system architecture while enhancing signal versatility. Engineered for industrial environments, the CC‑PUIO01 enables seamless connection of diverse field devices—such as sensors, actuators, switches, and transducers—into the control system, improving overall monitoring and control efficiency.
Technical Specifications
| Specification | Details |
|---|---|
| Model | CC‑PUIO01 (51454205‑175) |
| Product Type | Universal I/O Module |
| System Compatibility | Honeywell C300 Distributed Control Systems |
| Supported I/O | Analog inputs/outputs and digital inputs/outputs |
| Input Types | Analog (4–20 mA, 0–10 V), digital logic/pulse inputs |
| Output Types | Analog (4–20 mA, 0–10 V), digital logic outputs |
| Channels | Configurable mixed I/O channel count |
| Resolution | 16‑bit ADC/DAC for analog channels |
| Accuracy | ±0.1 % of full scale (analog) |
| Isolation | Channel‑to‑system electrical isolation |
| Operating Voltage | 24 V DC nominal |
| Operating Temperature | −20 °C to +70 °C |
| Humidity Range | 5 % to 95 % non‑condensing |
| Mounting | Rack or backplane installation |
| Dimensions (L × W × H) | Approx. 160 mm × 25 mm × 100 mm |
| Weight | Approx. 0.45 kg |
