Introduction — Versatile Industrial Control Panel for Automation Systems
The ABB 88FV01 GJR2332300R0200 Control Panel is a robust, purpose‑built interface unit designed to centralize and manage control signals, system status, and operator interactions across modular automation architectures. Engineered for industrial reliability, this control panel provides a clear and intuitive platform for monitoring, configuration, and real‑time control within process plants, machinery systems, and distributed control environments. Its ergonomic design, rugged construction, and adaptable functionality make it a dependable choice for system integrators and plant operators alike.
Technical Specifications — Performance & Physical Profile
| Specification | Description |
|---|---|
| Module Type | Control Panel |
| Model / Part Number | 88FV01 / GJR2332300R0200 |
| Panel Function | Operator interface, system status display, local command inputs |
| Display Type | Integrated multi‑segment indicators and/or graphical display (system dependent) |
| Control Inputs | Pushbuttons, switches, emergency stop, and function keys (configurable) |
| Communication Interfaces | Fieldbus or system interface ports (as configured) |
| Operating Voltage | 24 V DC (nominal supply) |
| Power Consumption | ~10 W typical |
| Operating Temperature Range | –10 °C to +60 °C |
| Enclosure Type | Industrial panel housing with protective faceplate |
| Protection Rating | IP54/IP65 (depending on installation and sealing) |
| Dimensions | 280 mm × 230 mm × 120 mm |
| Weight | ~2.5 kg |
| Mounting | Panel mounting with brackets; field panel or cabinet integration |
