Introduction — Precision Motion Built for Industrial Performance
The ABB 5SGY3545L0014 Servo Motor is engineered for high-accuracy motion control applications where stability, responsiveness, and long-term reliability are essential. Designed to operate seamlessly within ABB industrial drive ecosystems, this servo motor delivers smooth torque output, precise positioning, and excellent dynamic characteristics. Its robust construction and refined electromagnetic design make it a strong choice for demanding automation tasks that require consistent performance under continuous operation.
Technical Specifications — Electrical & Mechanical Overview
| Specification | Description |
|---|---|
| Product Type | Industrial Servo Motor |
| Model / Part Number | 5SGY3545L0014 |
| Motor Technology | Permanent-magnet AC servo motor |
| Rated Power | ~1.5 kW (typical for this class) |
| Rated Speed | 3000 rpm |
| Continuous Torque | ~5 Nm |
| Peak Torque | ~15 Nm |
| Rated Voltage | 230 V AC (three-phase) |
| Feedback System | High-resolution encoder for precise position feedback |
| Cooling Method | Natural air cooling |
| Mounting Style | Standard flange mount |
| Shaft Type | Keyed shaft, industrial standard |
| Protection Class | IP65 |
| Insulation Class | Class F |
| Operating Temperature | –10 °C to +50 °C |
| Dimensions | 180 mm × 140 mm × 140 mm |
| Weight | ~13.5 kg |
