Bently Nevada 330171-15-30-10-02-05 3300 5mm Proximity Probe

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Bently Nevada 330171-15-30-10-02-05 3300 5mm Proximity Probe

Name: Bently Nevada 330171-15-30-10-02-05 3300 5mm Proximity Probe
Brand: Bently Nevada PLC
SKU: 10053
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Bently Nevada PLC
Item No.:330171-15-30-10-02-05
Product Origin:USA
Product Dimensions:Total Length:1.0 meter
Product Weight:0.3kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

330171-00-08-90-01-05-3 330171-00-08-90-01-05-1 330171-00-08-90-01-05-4 330171-00-08-90-01-05-2

The Bently Nevada 330171-15-30-10-02-05 is a 3300 5 mm Proximity Probe designed for non-contact measurement of shaft vibration, axial position, Keyphasor® (speed/reference), and other rotating machinery parameters. It is part of the 3300 5 mm Proximity Transducer System, which consists of a 3300 5 mm probe, a 3300 XL extension cable, and a 3300 XL Proximitor® Sensor. When used together, the system provides a voltage output proportional to the distance between the probe tip and the conductive target.

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Part Number	330171-15-30-10-02-05
Product Type	3300 5 mm Proximity Probe
Probe Diameter	5 mm
Thread	1/4-28 UNF
Armor	Without armor
Unthreaded Length	1.5 in (Option 15)
Overall Case Length	3.0 in (Option 30)
Total Cable Length	1.0 m (3.3 ft) (Option 10)
Connector	Miniature coaxial ClickLoc®, standard cable (Option 02)
Agency Approval	Multiple Approvals (Option 05)
Probe Temperature Range	–35°C to +177°C (–31°F to +351°F)

Typical Applications

The 330171-15-30-10-02-05 is commonly used for:

Steam turbines
Gas turbines
Centrifugal compressors
Pumps
Electric motors
Gearboxes
Generators
Critical rotating machinery

Typical measurements include:

Radial shaft vibration
Axial position (thrust)
Shaft eccentricity
Keyphasor® speed/reference signals
Rotor dynamic analysis

Key Features

Non-contact eddy-current sensing for accurate shaft vibration and position measurements.
5 mm probe tip for applications with limited installation space.
1/4-28 UNF threaded probe without armor for standard installations.
ClickLoc® miniature coaxial connector provides secure and reliable connections.
Multiple hazardous-area approvals (Option 05) for certified industrial environments.
Fully compatible with 3300 XL extension cables and 3300 XL Proximitor® Sensors.
Designed for continuous operation on fluid-film bearing machinery in accordance with API 670 applications.

Frequently Asked Questions

What does the "15" option represent?
It specifies a 1.5-inch unthreaded length.

What does the "30" option represent?
It specifies a 3.0-inch overall probe case length.

What does the "10" option indicate?
It specifies a 1.0-meter (3.3-foot) total system length.

What is connector option "02"?
A miniature coaxial ClickLoc® connector with standard cable.

What does approval option "05" mean?
It indicates the probe has multiple hazardous-area approvals (such as CSA, ATEX, and IECEx, depending on the certification guide).

Can this probe be used by itself?
No. It is designed to operate as part of the complete 3300 5 mm Transducer System, together with a compatible 3300 XL extension cable and 3300 XL Proximitor® Sensor.
