Frequently Asked Questions

1. What is the primary use of the 330171-00-20-05-02-00?
It is used for continuous monitoring of shaft vibration, radial displacement, shaft position, and rotational speed on critical rotating machinery.

2. What does the "20" option indicate?
It specifies a 2.0-inch (50.8 mm) overall probe case length.

3. How long is the integral cable?
The 05 option indicates a 0.5-meter (1.6-foot) integral triaxial cable.

4. What connector does this probe use?
It uses a Miniature coaxial ClickLoc® connector (Option 02).

5. What does the final "00" mean?
It indicates the probe is supplied without hazardous-area agency approvals. For certified installations, versions with options such as 05 or CN may be required.

6. Can the probe operate by itself?
No. It must be paired with a compatible 3300 XL Extension Cable and 3300 XL Proximitor® Sensor as a complete calibrated system.

7. What industries commonly use this probe?
Oil & gas, power generation, petrochemical, mining, marine, and other industries using critical rotating machinery.

8. What is the operating temperature range?
The probe operates from -35°C to +177°C (-31°F to +351°F).
